Year of manufacture 2010
Working dimension X 2.670 mm
Working dimension Y 1.275 mm
Working dimension Z 280 mm
Number of routing spindles 1
HOLZ-HER 7831 Milling spindle
Main motor power 11 kW
Rotation speed max 18.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 6
6-position disk disc tool changer
Vertical drilling spindles 10
HOLZ-HER Drilling aggregate 7979
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Positioning aid
Crosshair laser
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Barcode reader
Safety device Safety mat
Interface for .dxf data
Handheld terminal
Pendulum machining
Workpiece support aids
Control PC control
Software DIREKT CNC NC-HOPS 5.6, PC office licence
Declaration of CE-conformity
Conformity marking CE mark
Total connection 22 kW
Weight 3.120 kg
Space requirement Length 5,5 m
Space requirement Width 3,9 m
Space requirement Height 2,5 m
