Year of manufacture 2010
Working dimension X 2.690 mm
Working dimension Y 1.230 mm
Working dimension Z 378 mm
Number of milling spindles 1
HOLZ-HER 7831 Milling spindle
Main motor power 6,5 kW
Rotation speed max 18.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 8
Disc tool changer 8-fold
Vertical drilling spindles 10
HOLZ-HER Drilling aggregate 7979
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
4-field processing
Positioning aid
Crosshair laser
Vacuum pump
Number of vacuum pumps 1
Barcode reader
Safety device Safety mat
Handheld terminal
Pendulum machining
Workpiece support aids
Control PC control
Software DIREKT CNC NC-HOPS 5.6
Conformity marking CE mark
