Year of manufacture 2010
Edgeband thickness max 25 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 70 mm
Feed min 10 m/min
Feedrate max 20 m/min
Continuously variable feed
Electromotoric height adjustment
Places in coil magazine 2
Glue system cartridge
Glue system granulate glue pot above feeding chain
Quick-change glue pot
Suitable for PUR glue
Magazine for single strips
Spraying device
Premilling unit
Trimming saw 2 motors
Flush/radius/chamfer milling units 3
Corner rounding unit 2 motors
Nutfräsaggregat Nutfräsaggregat starr
Scraper unit Profile scraper, Flat scraper
Buffing unit
Aggregates actuated by control NC-axes
Type Right-side machine
Machine length 9.350 mm
Control OTT PANEL LODGE V4
Conformity marking CE mark
Total connection 29,6 kW
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
https://www.hoechsmann.com/71859
2025-05-27 12:57:21
- Germany
- Second hand
