Year of manufacture 2019
Edgeband thickness max 12 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece width min 70 mm
Feed min 8 m/min
Feedrate max 18 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Glue system granulate Premelting unit
Spraying device
Premilling unit
Preheating zone
Andruckzone NC-gesteuert
Trimming saw 2 motors
Flush/radius/chamfer milling units 1
Corner rounding unit 2 motors
HOMAG Corner rounding unit MF 50
Scraper unit Profile scraper, Flat scraper
HOMAG Scraper unit MZ 40 Multistage scraper unit
Buffing unit
Aggregates actuated by control NC-axes
Type Right-side machine
Machine length 5.760 mm
Air cushion table on edgebanders
Control Homag powerTouch
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/88744
2025-10-30 11:37:24
- Germany
- Second hand
