Year of manufacture 2010
Edgeband thickness max 25 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 70 mm
Feed min 10 m/min
Feedrate max 20 m/min
Continuously variable feed
Electromotoric height adjustment
Places in coil magazine 2
Glue system granulate glue pot above feeding chain
OTT Glue system CM CombiMelt
Quick-change glue pot
Suitable for PUR glue
Magazine for single strips
Spraying device
Premilling unit
Trimming saw 2 motors
Flush/radius/chamfer milling units 3
Corner rounding unit 2 motors
Nutfräsaggregat Nutfräsaggregat starr
Scraper unit Profile scraper, Flat scraper
Aggregates actuated by control NC-axes
Type Right-side machine
Machine length 10.050 mm
Control OTT PANEL LODGE V4
Declaration of CE-conformity
Conformity marking CE mark
Total connection 29,6 kW
Weight 4.800 kg
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
