Year of manufacture 2019
Working dimension X 3.140 mm
Working dimension Y 1.560 mm
Working dimension Z 245 mm
Number of routing spindles 1
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Vertical drilling spindles 17
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 2
Groove saw in Y-direction, in X-direction
Gantry machine single-sided driven
Machine table Pod and rail table
Number of consoles 6
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Special workpiece clamping system For doors, For windows
BIESSE Uniclamp
Quantity of special clamps 4
Safety device Bumper
Three stop ranges
Workpiece support aids
Handheld terminal
Control PC control
Conformity marking CE mark, EAC mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/89750
2025-10-28 08:04:37
- Germany
- Second hand
