Year of manufacture 2016
Working dimension X 3.700 mm
Working dimension Y 2.100 mm
Working dimension Z 100 mm
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 9 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
5th axis Aggregate interface
HOMAG Flex 5 interface
Tool clamping system HSK-F63
Tool changer positions 28
Disc tool changer 14-fold
Number of exchangeable units 1
HOMAG Flex 5 aggregate
Vertical drilling spindles 21
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Gantry machine Yes
Machine table Matrix table
Vacuum pump
Number of vacuum pumps 3
Capacity vacuum pump 1.080 m³/h
Outfeed Conveyor belt, discharge unit
Safety device Safety mat
WEEKE Tool length control
Pendulum machining
Control HOMAG POWER CONTROL, Homag powerTouch
Software HOMAG WOODWOP 7.0
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
