Year of manufacture 2015
Working dimension X 3.280 mm
Working dimension Y 1.660 mm
Working dimension Z 225 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
Linear tool changer
Disc tool changer 16-fold
Vertical drilling spindles 20
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in Y-direction, in X-direction
BIESSE Drilling aggregate BH 30 2L
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Three stop ranges
Number of consoles 6
Pneumatic pipe connectors an den Saugerplattformen
Self-adjusting machine table
BIESSE Automatic machine table EPS
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Special workpiece clamping system For narrow workpieces
Anzahl Sonderspanner 6
BIESSE Uniclamp
Safety device Safety mat
Chip conveyor
Interface for .dxf data
Automatic lubrication
Control BIESSE BH 660
BIESSE Remote control unit RM 850
Software DIREKT CNC NC-HOPS, BIESSE BIESSEWORKS
Conformity marking CE mark
Total connection 18,4 kW
Weight 5.150 kg
Space requirement Length 6,8 m
Space requirement Width 4,9 m
Space requirement Height 2,8 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
