Year of manufacture 2012
Working dimension X 4.375 mm
Working dimension Y 1.550 mm
Working dimension Z 250 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 18,5 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
5th axis Aggregate interface
HOMAG Flex 5 Plus interface
Tool clamping system HSK-F63
Tool changer positions 18
Number of exchangeable units 2
HOMAG SÄGE- KAPPAGGREGAT
HOMAG KOMBIAGGREGAT BÜNDIG/RADIUS Flush milling / radius scraper
Vertical drilling spindles 25
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Edgebanding aggregate Unit, changeable
HOMAG powerEdge
Edgeband height max 65 mm
Gantry machine Yes
Machine table Pod and rail table
Two rows of stops
Workpiece support aids
Number of consoles 8
Pneumatic pipe connectors Yes
Positioning aid
LED luminous tape
Vacuum pump
Number of vacuum pumps 2
Capacity vacuum pump 180 m³/h
Safety device Bumper
Chip conveyor
HOMAG Quality package
Enclosed drag chain
Control HOMAG POWER CONTROL PC 85
Software HOMAG WOODWOP 6.0
Declaration of CE-conformity
Conformity marking CE mark
Total connection 24 kW
Weight 6.300 kg
Space requirement Length 8,6 m
Space requirement Width 4,5 m
Space requirement Height 2,95 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
