Year of manufacture 2009
Working dimension X 4.100 mm
Working dimension Y 1.445 mm
Working dimension Z 175 mm
Independent Z-axes 345
Number of milling spindles 1
Main motor power 11 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 18
Vertical drilling spindles 18
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Two rows of stops
Stop for top layer protrusion
Number of consoles 8
Positioning aid
Laser projector
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 140 m³/h
Safety device Safety mat
Interface for .dxf data
Control PC control
Software HOLZ-HER CAMPUS NC-HOPS
Declaration of CE-conformity
Conformity marking CE mark
Total connection 22 kW
Space requirement Length 7,8 m
Space requirement Width 3,83 m
Space requirement Height 2,5 m
https://www.hoechsmann.com/83787
2025-11-17 08:59:39
- Germany
- Second hand
