Year of manufacture 2012
Working dimension X 3.530 mm
Working dimension Y 1.270 mm
Working dimension Z 180 mm
Number of milling spindles 1
Main motor power 11 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 12
Number of exchangeable units 1
Vertical drilling spindles 10
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Lock recess milling aggregate Unit, changeable
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Positioning aid
Crosshair laser
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 100 m³/h
Safety device Light barrier
Interface for .dxf data
Control PC control
Declaration of CE-conformity
Conformity marking CE mark
Total connection 22 kW
Weight 2.850 kg
Space requirement Length 6,2 m
Space requirement Width 3,9 m
Space requirement Height 2,5 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/74751
2025-09-10 14:50:16
- Germany
- Second hand
