Year of manufacture 2018
Working dimension X 3.100 mm
Working dimension Y 1.415 mm
Working dimension Z 160 mm
Number of milling spindles 1
Main motor power 10 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
HOMAG DRIVE 5 CS
Tool clamping system HSK-F63
Tool changer positions 21
Linear tool changer
Disc tool changer 14-fold
Vertical drilling spindles 21
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw 90° turnable
Gantry machine einseitig angetrieben
Machine table Pod and rail table
Workpiece support aids
Two rows of stops
Stop for top layer protrusion
Pendulum machining
Number of consoles 6
Pneumatic pipe connectors central
Positioning aid
LED luminous tape
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 63 m³/h
Special workpiece clamping system For narrow workpieces, for frames
HOMAG Multiclamp
Anzahl Sonderspanner 4
Barcode reader
Safety device laser, Bumper
Chip conveyor
HOMAG Convenience package operation
HOMAG hand-controlled machine
HOMAG ecoPlus
HOMAG Quality package
Control HOMAG POWER CONTROL PC 86, Homag powerTouch
UPS - Uninterruptible Power Supply
Software HOMAG WOODWOP 7.2, woodScan, HOMAG MMR BASIC, HOMAG tapio ready
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/17729
2025-07-30 17:53:17
- Germany
- Second hand
