Year of manufacture 2022
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 150 mm
Workpiece width min 50 mm
Feedrate max 12 m/min
Glue system granulate glue pot below feeding chain
BIESSE Glue system SP 03
Quick-change glue pot
Suitable for PUR glue
Spraying device
BIESSE EDGE Spraying device ADZ
Premilling unit
BIESSE Premilling unit RT 02
Preheating zone
BIESSE Preheating zone IRL 700
Trimming saw 2 motors
BIESSE Trimming saw IT 03
Flush/radius/chamfer milling units 1
BIESSE Fine milling unit RF 02
Corner rounding unit 2 motors
BIESSE Corner rounding unit AR 02
Scraper unit Profile scraper, Flat scraper
BIESSE Profile scraper unit RB 03
BIESSE Flat scraper unit RC 02
Buffing unit
BIESSE Buffing unit SZ 02
Suitable for nesting Bündig/Radius/Fasestationen, Profile scraper
BIESSE Pro-Nesting Kit
Profilwechsel automatisch Bündig/Radius/Fasestationen
Type left-side machine
Machine length 5.213 mm
Control BIESSE SMART TOUCH 7 "
Conformity marking CE mark
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
