Year of manufacture 2019
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 160 mm
Workpiece width min 60 mm
Feed min 10 m/min
Feedrate max 18 m/min
Continuously variable feed
Electromotoric height adjustment
Glue system cartridge
HOLZ-HER Glue system GLU JET GJ 301
Suitable for PUR glue
Magazine for single strips
Spraying device
HOLZ-HER Spraying device TR 501
Premilling unit
HOLZ-HER Premilling unit 1802
Andruckzone NC-gesteuert
HOLZ-HER Pressure zone 1913 MOT
Trimming saw 2 motors
HOLZ-HER Trimming saw 1918/60 PNEU
Flush/radius/chamfer milling units 1
HOLZ-HER Fine milling unit FR 701
Corner rounding unit 2 motors
HOLZ-HER Corner rounding unit FF 701
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit 1929 MOT4
HOLZ-HER Scraper unit FK 701
Buffing unit
HOLZ-HER Buffing unit 1940
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 5.590 mm
Control HOLZ-HER EDGECONTROL TOUCH PPC 319
Declaration of CE-conformity
Conformity marking CE mark
Total connection 6,3 kW
Weight 2.100 kg
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/84997
2025-08-14 07:35:10
- Germany
- Second hand
