Year of manufacture 2017
Working dimension X 5.020 mm
Working dimension Y 1.830 mm
Working dimension Z 220 mm
Independent Z-axes 2
Number of milling spindles 2
SCM 5-axes spindle PRISMA HP
Milling spindle liquid-cooled
SCM Chip deflector
SCM Milling spindle PB 1
Main motor power 17 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool changer positions 34
Disc tool changer 18-fold
SCM Tool changer RAPID 10
SCM Tool changer RAPID 6
Vertical drilling spindles 25
Horizontal drilling spindles in X 8
Horizontal drilling spindles in Y 4
Groove saw 90° turnable
SCM Drilling aggregate F 37 L2
Edgebanding aggregate Seperate Y-axis
SCM Edgebanding aggregate H80
Edgeband height max 84 mm
Places in coil magazine 2
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table
Stop for top layer protrusion
Workpiece support aids
Two rows of stops
Number of consoles 8
Self-adjusting machine table
SCM Machine table MATIC
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Safety mat
Chip conveyor
Interface for .dxf data
SCM SAVENERGY
Tool charge measurement
SCM TecPad
Control PC control
Software SCM MAESTRO EDGE
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/87818
2025-09-15 10:52:31
- Germany
- Second hand
