Year of manufacture 2016
Working dimension X 4.825 mm
Working dimension Y 1.950 mm
Working dimension Z 400 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 22
Chain changer 22 positions
Vertical drilling spindles 16
BIESSE Drilling aggregate BH 29 L
Horizontal drilling spindles in X 8
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Gantry machine Yes
Machine table Pod and rail table
Number of consoles 8
Self-adjusting machine table
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Safety mat
Chip conveyor
Interface for .dxf data
Two rows of stops
BIESSE Automatic machine table EPS
Workpiece support aids
Remote control
Automatic lubrication
Control BIESSE BH 660
Software BIESSE B_SOLID
Conformity marking CE mark, EAC mark
Total connection 20 kW
Weight 6.350 kg
Space requirement Length 9,334 m
Space requirement Width 6,567 m
Space requirement Height 3,37 m
Technical data are partly estimated. Actual values may differ.
Das Foto der Betriebsstunden ist von 09.2023.
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
