Year of manufacture 2011
Working dimension X 4.200 mm
Working dimension Y 1.535 mm
Working dimension Z 230 mm
Independent Z-axes 2
Number of milling spindles 2
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 66
Vertical drilling spindles 5
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Groove saw with own C-axis
Cantilever machine
Machine table Pod and rail table
Number of consoles 10
Self-adjusting machine table
Vacuum pump
Capacity vacuum pump 250 m³/h
Special workpiece clamping system For windows
Feeding belt conveyor
Outfeed belt conveyor
Safety device Safety mat
Chip conveyor
Interface for .dxf data
BIESSE Automatic machine table EPS
RFID-based tool management
BIESSE Flexstore
BIESSE Multifunction units
BIESSE Drilling aggregate BH 9
BIESSE UNICLAMP
Automatic central lubrication
Three stop ranges
Control BIESSE XP 600
Software DIREKT CNC WORK CENTER SAUGERVORSCHLAG, DIREKT CNC ACADEMY, DIREKT CNC NC-HOPS 5
Total connection 21,1 kW
Weight 8.040 kg
Spindle power estimated
https://www.hoechsmann.com/90250
2025-09-11 14:30:28
- Germany
- Second hand
