Year of manufacture 2019
Edgeband thickness max 22 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 145 mm
Workpiece width min 95 mm
Feed min 10 m/min
Feedrate max 25 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Zero joint Hot air
SCM AirFusion+
Glue system granulate glue pot above feeding chain
SCM Glue system VC 600-12 /QMS
Quick-change glue pot
Suitable for PUR glue
SCM Glue system PU BOX L
Spraying device
SCM Spraying device AAR Anti-adhesive spray unit
Premilling unit
STEFANI Premilling unit RT-H
Trimming saw 2 motors
STEFANI Trimming saw YU/SP 750
Flush/radius/chamfer milling units 1
STEFANI Fine milling unit RSU
Corner rounding unit 4 motors
SCM Corner rounding unit ROUND 4
Scraper unit Profile scraper, Flat scraper
SCM Scraper unit RC S-E
STEFANI Scraper unit RCA 2C
Buffing unit
SCM Buffing unit SP E
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 7.250 mm
Control SCM eye-M
Software SCM MAESTRO PRO-EDGE
Conformity marking CE mark
https://www.hoechsmann.com/33243
2025-09-12 11:36:38
- Germany
- Second hand
