Year of manufacture 2008
Working dimension X 3.200 mm
Working dimension Y 1.259 mm
Working dimension Z 280 mm
Number of milling spindles 1
HOLZ-HER 7933 Milling spindle
Milling spindle liquid-cooled
Main motor power 11 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 18
HOLZ-HER Tool changer 7996
Vertical drilling spindles 18
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
HOLZ-HER 7960
Lock recess milling aggregate permanently attached
HOLZ-HER 7982 Lock case milling aggregate
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Number of consoles 6
Positioning aid
Point-type laser
Safety device Safety mat
Interface for .dxf data
Control HOLZ-HER KPL
Control cabinet cooling
Software HOLZ-HER CAMPUS
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
