Year of manufacture 2019
Working dimension X 3.050 mm
Working dimension Y 1.250 mm
Working dimension Z 80 mm
Number of milling spindles 1
Main motor power 10 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 4
Vertical drilling spindles 15
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw 90° turnable
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Dowel insertion
Glue system PVAc
Dowel diameter 8 mm
Dowel length max 40 mm
Safety device enclosed cabin
HOMAG ecoPlus
Control Homag powerTouch, HOMAG POWER CONTROL
Software HOMAG WOODWOP 7.1, MICROSOFT WINDOWS 7, HOMAG tapio ready
HOMAG Plausibility check
Declaration of CE-conformity
Conformity marking CE mark
Total connection 16 kW
Weight 3.600 kg
Space requirement Length 4,8 m
Space requirement Width 2,4 m
Space requirement Height 2,7 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
