Year of manufacture 2018
Working dimension X 3.280 mm
Working dimension Y 1.660 mm
Working dimension Z 245 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
Disc tool changer
Linear tool changer
Vertical drilling spindles 10
BIESSE Drilling aggregate BH 17 L
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Three stop ranges
Electronic supervision of the end-position of the stops
Number of consoles 6
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Special workpiece clamping system Clamps for beams, For doors
Safety device Safety mat
Chip conveyor
Interface for .dxf data
Control BIESSE BH 660
Software BIESSE B_SOLID
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/79653
2025-10-28 21:00:03
- Germany
- Second hand
