Year of manufacture 2008
Working dimension X 4.175 mm
Working dimension Y 1.550 mm
Working dimension Z 300 mm
Independent Z-axes 2
Number of milling spindles 2
Main motor power 15 kW
Milling spindle liquid-cooled
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
5th axis Aggregate interface
HOMAG Flex 5 Plus interface
Tool clamping system HSK-F63
Tool changer positions 33
Disc tool changer 18-fold
Disc tool changer 10-fold
Linear tool changer
Tool changing auxiliary device
Vertical drilling spindles 20
HOMAG Multi Processing Unit
Horizontal drilling spindles in X 10
Horizontal drilling spindles in Y 10
Groove saw with own C-axis
Cantilever machine
Machine table Pod and rail table
HOMAG K-table
Workpiece support aids
Two rows of stops
Number of consoles 8
Positioning aid
LED luminous tape
Safety device Safety mat
HOMAG Quality package
Enclosed drag chain
Control HOMAG POWER CONTROL PC 85
UPS - Uninterruptible Power Supply
Handheld terminal
Software HOMAG WOODWOP 8.0
Conformity marking CE mark
Power second spindle 6kW
https://www.hoechsmann.com/55581
2025-07-22 23:55:03
- Germany
- Second hand
