Year of manufacture 2016
Edgeband thickness max 8 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 160 mm
Workpiece width min 60 mm
Feedrate max 18 m/min
Continuously variable feed
Electromotoric height adjustment
Glue system cartridge
Glue system granulate direktes Aufschmelzsystem
HOLZ-HER Glue system GLU JET GJ 301
Suitable for PUR glue
Magazine for single strips
Spraying device
HOLZ-HER Spraying device 1856
Premilling unit
HOLZ-HER Premilling unit 1802
Preheating zone
HOLZ-HER Preheating zone ZH 701
Andruckzone NC-gesteuert
Trimming saw 2 motors
HOLZ-HER Trimming saw 1918 PNEU
Flush/radius/chamfer milling units 1
HOLZ-HER Fine milling unit 1826 MOT4
Corner rounding unit 2 motors
HOLZ-HER Corner rounding unit 1833 MOT4
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit 1929 MOT4
HOLZ-HER Scraper unit FK 701
Buffing unit
HOLZ-HER Buffing unit 1940
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 5.696 mm
Control HOLZ-HER EDGECONTROL TOUCH PPC 319
Conformity marking CE mark
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
