Working dimension X 6.000 mm
Working dimension Y 260 mm
Working dimension Z 100 mm
Independent Z-axes 2
Number of milling spindles 2
Main motor power 30 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 183
Bauform Standportalmaschine Yes
Machine table Feed-through technology, Special execution
WEINIG PowerGrip
Self-adjusting machine table
Workpiece probing
Special workpiece clamping system For windows, for small workpieces
Feeding belt conveyor
Outfeed Conveyor belt
Safety device enclosed fence, enclosed cabin
Automatic central lubrication
Plausibility check
Workpiece length measurement
Workpiece width measuring
Werkstückdickenmessung
Control SIEMENS SIMATIC S7, SIEMENS SINUMERIK 840 D, WEINIG NEXUS
Conformity marking CE mark
Space requirement Length 18,5 m
Space requirement Width 6,5 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
5-axis spindle:
-liquid-cooled
-Power S6, 22kW
-max. speed, 24000 rpm
4-axis spindle:
-Power S6, 30kW
-max. speed, 18000 rpm
https://www.hoechsmann.com/64506
2025-05-21 17:28:04
- Germany
- Second hand
