Year of manufacture 2016
Working dimension X 3.050 mm
Working dimension Y 850 mm
Working dimension Z 56 mm
Number of milling spindles 1
Main motor power 5 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 4
Vertical drilling spindles 13
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Interface for .dxf data
HOMAG ecoPlus
Control HOMAG POWER CONTROL, Homag powerTouch
Software HOMAG WOODWOP 7.0, HOMAG WOODVISIO, HOMAG WOODASSEMBLER, HOMAG WOODWOP AV-PAKET, HOMAG WOODWOP DXF-IMPORT Basic, HOMAG 3D CNC-SIMULATION
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
