Year of manufacture 2022
Working dimension X 3.300 mm
Working dimension Y 1.250 mm
Working dimension Z 150 mm
Number of milling spindles 1
Main motor power 12 kW
Rotation speed max 24.000 rpm
Torque support
Tool clamping system HSK-F63
Tool changer positions 12
Vertical drilling spindles 18
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in Y-direction, in X-direction
Gantry machine einseitig angetrieben
Machine table Pod and rail table
Two rows of stops
Workpiece support aids
Number of consoles 6
Positioning aid
Laser projector
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Safety device Bumper
Pendulum machining
Interface for .dxf data
Automatic central lubrication
Control FORMAT 4 F4 INTEGRATE
Handheld terminal
Software FORMAT 4 F4 OPERATE, FORMAT 4 F4 TOOLBOX, FORMAT 4 F4 CREATE, PC office licence
Conformity marking CE mark, UKCA-Zeichen
Total connection 18 kW
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
