Year of manufacture 2009
Working dimension X 3.200 mm
Working dimension Y 1.287 mm
Working dimension Z 250 mm
Number of milling spindles 1
HOLZ-HER 7831 Milling spindle
Main motor power 11 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 8
Disc tool changer 8-fold
Vertical drilling spindles 10
Horizontal drilling spindles in X 2
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Positioning aid
Point-type laser
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 100 m³/h
Safety device Safety mat
Interface for .dxf data
Control PC control
Control cabinet cooling
Software HOLZ-HER CAMPUS
Conformity marking CE mark
Total connection 22 kW
Weight 3.590 kg
Space requirement Length 6,2 m
Space requirement Width 3,9 m
Space requirement Height 2,5 m
https://www.hoechsmann.com/61151
2025-04-25 19:10:27
- Germany
- Second hand
