Year of manufacture 2008
Working dimension X 3.000 mm
Working dimension Y 1.000 mm
Working dimension Z 60 mm
Independent Z-axes 2
Number of milling spindles 2
Main motor power 3,5 kW
Rotation speed max 18.000 rpm
Tool clamping system HSK-D50
Vertical drilling spindles 58
Horizontal drilling spindles in X 16
Horizontal drilling spindles in Y 4
Cantilever machine
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Outfeed belt conveyor
Safety device Safety mat, enclosed fence
Interface for .dxf data
Workpiece length measurement
Workpiece width measuring
Control BIESSE XP 600
Software BIESSE BIESSEWORKS
Plausibility check
Conformity marking CE mark
Weight 2.700 kg
Instead of the lower grooving saw unit, a horizontal drilling/milling unit is installed in the -Y direction (workpiece processing on all sides).
https://www.hoechsmann.com/23676
2025-03-28 18:28:56
- Germany
- Second hand
