Year of manufacture 2017
Working dimension X 3.280 mm
Working dimension Y 1.600 mm
Working dimension Z 200 mm
Number of routing spindles 1
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
16-position disk disc tool changer
Linear tool changer
Vertical drilling spindles 20
BIESSE Drilling aggregate BH 30 2L
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Edgebanding aggregate Seperate Y-axis
Edgeband height max 65 mm
Places in coil magazine 2
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Self-adjusting machine table
BIESSE Automatic machine table EPS
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Safety mat
Chip conveyor
Three stop ranges
Workpiece support aids
Electronic supervision of the end-position of the stops
Automatic lubrication
Handheld terminal
Control BIESSE BH 660
Software BIESSE B_SOLID, BIESSE B_SUITE
Conformity marking CE mark, EAC mark
Total connection 19 kW
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
