Year of manufacture 2020
Working dimension X 4.320 mm
Working dimension Y 1.580 mm
Working dimension Z 200 mm
Independent Z-axes 3
Number of milling spindles 1
Milling spindle liquid-cooled
Blow-off device
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 28
Disc tool changer 16-fold
Linear tool changer
Vertical drilling spindles 13
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw in X-direction
BIESSE Drilling aggregate BH 24 L
Edgebanding aggregate Seperate Y-axis
Edgeband height max 65 mm
Places in coil magazine 2
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Electronic supervision of the end-position of the stops
Two rows of stops
Number of consoles 8
Pneumatic pipe connectors an den Saugerplattformen
BIESSE Preparation for Uniclamp
4-field processing
Self-adjusting machine table
BIESSE Automatic machine table EPS
Vacuum pump
Number of vacuum pumps 1
Special workpiece clamping system For windows, For narrow workpieces, for frames
BIESSE Uniclamp
Anzahl Sonderspanner 2
Safety device Bumper, Light barrier
Chip conveyor
Interface for .dxf data
Control BIESSE BH 660
BIESSE Remote control unit RM 850
Software BIESSE B_SOLID
Space requirement Length 8,1 m
Space requirement Width 5,5 m
Space requirement Height 2,7 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
