Year of manufacture 2013
Working dimension X 3.280 mm
Working dimension Y 1.320 mm
Working dimension Z 170 mm
Independent Z-axes 2
Number of milling spindles 1
Main motor power 11 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 16
Number of exchangeable units 2
Vertical drilling spindles 16
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Edgebanding aggregate Seperate Y-axis, Unit, changeable
Edgeband height max 64 mm
Places in coil magazine 2
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Safety mat
Interface for .dxf data
BIESSE Preparation for Uniclamp
BIESSE Machine table ATS
BIESSE Drilling aggregate BH 26
Two rows of stops
Workpiece support aids
Milling spindle liquid-cooled
Control cabinet cooling
Control BIESSE BH 660
Software BIESSE BIESSEWORKS
Declaration of CE-conformity
Conformity marking CE mark
Total connection 17 kW
Weight 4.310 kg
Space requirement Length 6 m
Space requirement Width 5,2 m
Space requirement Height 2,9 m
