Year of manufacture 2014
Working dimension X 3.050 mm
Working dimension Y 850 mm
Working dimension Z 60 mm
Number of routing spindles 1
Main motor power 5 kW
Rotation speed max 18.000 rpm
Tool clamping system ETP 25
Vertical drilling spindles 8
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Control HOMAG POWER CONTROL PC 85
Software HOMAG WOODWOP 6.1
Declaration of CE-conformity
Conformity marking CE mark
Total connection 11,5 kW
Weight 1.580 kg
Space requirement Length 3 m
Space requirement Width 1,6 m
Space requirement Height 1,9 m
https://www.hoechsmann.com/87059
2025-08-12 13:30:37
- Germany
- Second hand
