Year of manufacture 2021
Working dimension X 3.050 mm
Working dimension Y 850 mm
Working dimension Z 60 mm
Number of routing spindles 1
Main motor power 10 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 4
Vertical drilling spindles 13
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Control Homag powerTouch, HOMAG POWER CONTROL
Software HOMAG WOODWOP 7.2
Declaration of CE-conformity
Conformity marking CE mark
Total connection 11,5 kW
Weight 2.000 kg
Space requirement Length 3,2 m
Space requirement Width 2 m
Space requirement Height 2 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
