Year of manufacture 2019
Working dimension X 3.100 mm
Working dimension Y 2.250 mm
Working dimension Z 210 mm
Independent Z-axes 3
Number of routing spindles 1
Blow-off device
Main motor power 10 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
5th axis Aggregate interface
HOMAG Flex 5 interface
Tool clamping system HSK-F63
Tool changer positions 14
WEEKE Tool changer W 14 Disc tool changer in the back
Vertical drilling spindles 21
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw 90° turnable
Gantry machine double-sided driven moving gantry
Machine table Matrix table
HOMAG MATRIX table PRO
Electronic end position detection
Air cushion function
Quantity vacuum zones 4
Vacuum pump
Number of vacuum pumps 3
Capacity vacuum pump 870 m³/h
Feeding Hedgehog magazine, Vacuum feed device
HOMAG Simultaneous push-off and infeed
Outfeed discharge unit, Conveyor belt
Safety device enclosed fence
Milling for fittings Lamello Cabineo
Insert fittings Yes
HOMAG Quality package
Automatic central lubrication
Tool charge measurement
Videocamera
Control HOMAG POWER CONTROL PC 86, Homag powerTouch
HOMAG ecoPlus
Software HOMAG WOODWOP 7.2, HOMAG WOODMOTION
Declaration of CE-conformity
Conformity marking CE mark
https://www.hoechsmann.com/3953
2022-06-20 11:50:29
- Germany
- Second hand
