Year of manufacture 2011
Working dimension X 6.175 mm
Working dimension Y 1.550 mm
Working dimension Z 300 mm
Independent Z-axes 3
Number of milling spindles 2
Main motor power 18,5 kW
Milling spindle liquid-cooled
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
5th axis Aggregate interface
HOMAG Flex 5 Plus interface
Tool clamping system HSK-F63
Tool changer positions 23
Disc tool changer 18-fold
HOMAG HOMAG Flex5 PLUS tool changer
Tool changing auxiliary device
Vertical drilling spindles 20
HOMAG Multi Processing Unit
Horizontal drilling spindles in X 10
Horizontal drilling spindles in Y 10
Groove saw with own C-axis
Edgebanding aggregate Seperate Y-axis
HOMAG Edgebanding aggregate POWER EDGE
Edgeband height max 65 mm
Places in coil magazine 2
Cantilever machine
Machine table Pod and rail table
Workpiece support aids
Number of consoles 10
Pneumatic pipe connectors an den Konsolen
4-field processing
Positioning aid
LED luminous tape
Safety device Safety mat
Enclosed drag chain
Control HOMAG POWER CONTROL PC 85
Software HOMAG WOODWOP 6.1
Conformity marking CE mark
Space requirement Length 11,25 m
Space requirement Width 5,5 m
Space requirement Height 2,95 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
