Year of manufacture 2021
Working dimension X 3.200 mm
Working dimension Y 1.250 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 11 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 8
Disc tool changer
Vertical drilling spindles 16
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper, Pressure rollers
Outfeed Workpiece return
Barcode reader
Safety device enclosed cabin, Safety mat, enclosed fence
Interface for .dxf data
Control PC control
Software BIESSE SOPHIA, BIESSE B_SOLID
Declaration of CE-conformity
Conformity marking CE mark, EAC mark
Total connection 21 kW
Weight 3.260 kg
Space requirement Length 10,3 m
Space requirement Width 4 m
Space requirement Height 3,4 m
