Year of manufacture 2024
Working dimension X 3.050 mm
Working dimension Y 1.300 mm
Working dimension Z 95 mm
Number of milling spindles 1
Main motor power 7,5 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 6
Vertical drilling spindles 21
Horizontal drilling spindles in X 6
Groove saw in X-direction
Vertical working surface
Machine table Feed-through technology
Workpiece probing
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Milling for fittings Lamello Clamex
Interface for .dxf data
Control SCM eye-M
Software SCM MAESTRO ACTIVE CNC
Conformity marking CE mark
Weight 2.602 kg
Space requirement Length 4,6 m
Space requirement Width 2,23 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
