Year of manufacture 2020
Working dimension X 6.360 mm
Working dimension Y 1.905 mm
Working dimension Z 350 mm
Number of milling spindles 2
SCM PRISMA MAXI
SCM 5-axes spindle PRISMA T
Chip deflector
Milling spindle liquid-cooled
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool changer positions 48
SCM Tool changer TRC 48 Chain changer
SCM MACH 5
Vertical drilling spindles 6
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw with own C-axis
SCM Drilling aggregate BRC
Lock recess milling aggregate with C-axis, double-sided
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table
Pendulum machining
Two rows of stops
Workpiece support aids
Number of consoles 8
Pneumatic pipe connectors an den Saugerplattformen
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Special workpiece clamping system For windows, For narrow workpieces
Chip conveyor
Interface for .dxf data
SCM RTCP
Enclosed drag chain
Control SCM eye-M
SCM TecPad
Control cabinet cooling
Software SCM MAESTRO ACTIVE CNC, MICROSOFT WINDOWS 10, SCM MAESTRO PRO VIEW
Conformity marking CE mark
Weight 8.000 kg
Space requirement Length 11,5 m
Space requirement Width 6,2 m
Space requirement Height 3 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
