Year of manufacture 2022
Working dimension X 5.600 mm
Working dimension Y 1.000 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 6,6 kW
Rotation speed max 20.000 rpm
Tool clamping system HSK-F63
Tool changer positions 3
Vertical drilling spindles 13
Horizontal drilling spindles in X 6
Horizontal drilling spindles in Y 4
Groove saw in X-direction
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Feeding Gripper
Safety device enclosed cabin
Control PC control
Software GANNOMAT EDITOR
Conformity marking CE mark
Total connection 12 kW
Space requirement Length 2,4 m
Space requirement Width 1,5 m
Space requirement Height 1,5 m
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
https://www.hoechsmann.com/49687
2026-05-13 13:56:53
- Germany
- Second hand
