Year of manufacture 2021
Working dimension X 5.600 mm
Working dimension Y 1.000 mm
Working dimension Z 60 mm
Number of milling spindles 1
Main motor power 4,5 kW
Rotation speed max 18.000 rpm
Torque support
Tool changer positions 6
Vertical drilling spindles 10
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Safety device enclosed cabin
Milling for fittings Lamello Clamex
Software MASTERWOOD MASTERWORK MW310
Conformity marking CE mark
Total connection 15,8 kW
Weight 1.420 kg
Space requirement Length 3,06 m
Space requirement Width 2,72 m
Space requirement Height 1,7 m
