Year of manufacture 2018
Edgeband thickness max 20 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 140 mm
Workpiece width min 60 mm
Feed min 10 m/min
Feedrate max 25 m/min
Continuously variable feed
Electromotoric height adjustment
Top pressure by belt
Glue system cartridge
HOLZ-HER Glue system GLU JET GJ 302
Quick-change glue pot
HOLZ-HER Glue system LTRONIC WECHSELSTATION
Suitable for PUR glue
Magazine for single strips
Spraying device
HOLZ-HER Spraying device 1856
Spraying device Release agent
Spraying device Cleaning agent
Premilling unit
HOLZ-HER Premilling unit 1804 MOT2
Andruckzone NC-gesteuert
Trimming saw 2 motors
HOLZ-HER Trimming saw KA 701
Flush/radius/chamfer milling units 2
HOLZ-HER Flush milling unit 1962 MOT3
HOLZ-HER Fine milling unit FR 701 MOT6 MULTI
Corner rounding unit 2 motors
HOLZ-HER Corner rounding unit FF 701 MOT6
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit ZK 701
HOLZ-HER Scraper unit FK 701
Buffing unit
HOLZ-HER Buffing unit 1851 K
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 10.390 mm
Air cushion table on edgebanders
Scissor support
HOLZ-HER ""Multifunction package""
Control HOLZ-HER EDGECONTROL TOUCH PPC 319
Conformity marking CE mark
* Prepared for a return device
* Prepared for retrofitting Ltronic - Ltronic ready
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
