Year of manufacture 2019
Working dimension X 3.000 mm
Working dimension Y 1.500 mm
Working dimension Z 250 mm
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 12 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 13
Linear tool changer
Pickup change place
Vertical drilling spindles 12
FORMAT 4 DH 18 6H 1S
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table
Two rows of stops
Number of consoles 6
Pneumatic pipe connectors Yes
Positioning aid
Laser setup aid
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Safety device Safety mat
Automatic central lubrication
Control PC control
Software FORMAT 4 WOOD FLASH
Hardlock
Declaration of CE-conformity
Conformity marking CE mark
Total connection 19 kW
Weight 2.840 kg
Space requirement Length 6,6 m
Space requirement Width 4,5 m
Space requirement Height 2,6 m
