Year of manufacture 2010
Working dimension X 3.100 mm
Working dimension Y 2.100 mm
Working dimension Z 240 mm
Number of milling spindles 1
HOLZ-HER 7830 Milling spindle
Main motor power 11 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 8
HOLZ-HER Tool changer 7896
Vertical drilling spindles 18
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
HOLZ-HER Drilling aggregate 7968
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Matrix table
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Suitable for nesting
Safety device Light barrier
Interface for .dxf data
Control PC control
Control cabinet cooling
Software HOLZ-HER CAMPUS NC-HOPS, HOLZ-HER CAMPUS V5, DIREKT CNC NC-HOPS 5.6
Declaration of CE-conformity
Conformity marking CE mark
Total connection 22 kW
Weight 5.475 kg
Space requirement Length 7,3 m
Space requirement Width 5 m
Space requirement Height 2,4 m
