Year of manufacture 2017
Working dimension X 5.055 mm
Working dimension Y 1.650 mm
Working dimension Z 290 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 13 kW
Rotation speed max 24.000 rpm
Torque support
4th axis Yes
5th axis 5-axes spindle
Tool clamping system HSK-F63
Tool changer positions 22
Chain changer
Vertical drilling spindles 20
BIESSE Drilling aggregate BH 30 2L
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 4
Groove saw in X-direction, in Y-direction
Gantry machine Yes
Machine table Pod and rail table
Number of consoles 8
Self-adjusting machine table
BIESSE Automatic machine table EPS
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 250 m³/h
Safety device Light barrier, Bumper
Chip conveyor
Three stop ranges
Tool changing auxiliary device
Workpiece support aids
Electronic supervision of the end-position of the stops
BIESSE Remote control unit RM 850
Automatic central lubrication
UPS - Uninterruptible Power Supply
Control cabinet cooling
Control BIESSE BH 660
Software BIESSE B_SOLID
Conformity marking CE mark, EAC mark
Total connection 28,2 kW
Weight 10.250 kg
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
