Year of manufacture 2015
Working dimension X 3.050 mm
Working dimension Y 1.250 mm
Working dimension Z 80 mm
Independent Z-axes 2
Number of milling spindles 1
Main motor power 9 kW
Rotation speed max 24.000 rpm
Tool clamping system HSK-F63
Tool changer positions 4
Vertical drilling spindles 20
WEEKE Split-Head
Horizontal drilling spindles in X 12
Horizontal drilling spindles in Y 4
Vertical working surface
Machine table Feed-through technology
Special workpiece clamping system clamp gripper
Barcode reader
Dowel insertion
Glue system PVAc
Dowel diameter 8 mm
Dowel length max 35 mm
Safety device enclosed cabin
Control HOMAG POWER CONTROL PC 86, Homag powerTouch
Plausibility check
Conformity marking CE mark
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/97592
2026-01-16 20:40:09
- Germany
- Second hand
