Year of manufacture 2010
Edgeband thickness max 15 mm
Panel thickness max 60 mm
Thickness of coiled edgeband max 3 mm
Workpiece length min 180 mm
Workpiece width min 60 mm
Feed min 10 m/min
Feedrate max 18 m/min
Continuously variable feed
Electromotoric height adjustment
Glue system cartridge
Suitable for PUR glue
Magazine for single strips
Premilling unit
HOLZ-HER Premilling unit 1802
Andruckzone NC-gesteuert
Trimming saw 2 motors
HOLZ-HER Trimming saw 1918
Flush/radius/chamfer milling units 1
HOLZ-HER Flush milling unit 1828
Corner rounding unit 2 motors
HOLZ-HER Corner rounding unit 1833 MOT4
Scraper unit Profile scraper, Flat scraper
HOLZ-HER Profile scraper unit 1929 MOT2
HOLZ-HER Flat scraper unit 1964
Aggregates actuated by control NC-axes
Type left-side machine
Machine length 5.195 mm
Control HOLZ-HER EDGECONTROL PPC 231
Please note that the information on maximum edge thickness, panel thickness and feed speed is aggregate-dependent and may vary depending on the specific processing situation.
Technical data are partly taken from the manufacturer's brochure. Actual values may differ.
