Year of manufacture 2009
Working dimension X 3.060 mm
Working dimension Y 1.260 mm
Working dimension Z 100 mm
Number of milling spindles 1
Main motor power 9 kW
Rotation speed max 24.000 rpm
Torque support
4th axis C-axis
Tool clamping system HSK-F63
Tool changer positions 11
Mitfahrender Linearwechsler
Pickup tool changer
Pickup change place
Vertical drilling spindles 14
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw in X-direction
Cantilever machine
Machine table Pod and rail table
Number of consoles 6
Pneumatic pipe connectors Yes, central
Positioning aid
Laser projector
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 90 m³/h
Safety device Safety mat
Interface for .dxf data
Pendulum machining
Two rows of stops
Stop for top layer protrusion
Automatic central lubrication
Control PC control
Hand-controlled machine
Software FORMAT 4 WOOD FLASH
Conformity marking CE mark
Total connection 15 kW
Weight 2.960 kg
Space requirement Length 6,4 m
Space requirement Width 4,5 m
Space requirement Height 2,4 m
https://www.hoechsmann.com/59103
2026-01-19 11:28:45
- Germany
- Second hand
