Year of manufacture 2018
Working dimension X 3.100 mm
Working dimension Y 1.415 mm
Working dimension Z 160 mm
Independent Z-axes 2
Number of milling spindles 1
Milling spindle liquid-cooled
Main motor power 10 kW
Rotation speed max 24.000 rpm
4th axis Yes
5th axis 5-axes spindle
HOMAG DRIVE 5 CS
Tool clamping system HSK-F63
Tool changer positions 15
Disc tool changer 8-fold
Linear tool changer
Tool changing auxiliary device
Vertical drilling spindles 12
Horizontal drilling spindles in X 4
Horizontal drilling spindles in Y 2
Groove saw 90° turnable
Gantry machine beidseitig angetriebene Gantrymaschine
Machine table Pod and rail table
Workpiece support aids
Two rows of stops
Number of consoles 6
Pneumatic pipe connectors central
Positioning aid
LED luminous tape
Vacuum pump
Number of vacuum pumps 1
Capacity vacuum pump 63 m³/h
Barcode reader
Safety device laser, Bumper
Control Homag powerTouch
HOMAG Convenience package operation
Software HOMAG WOODWOP 7.0
Conformity marking CE mark
Space requirement Length 6,9 m
Space requirement Width 4,55 m
Space requirement Height 2,65 m
Unless expressly stated, tools, tool holders, aggregates, and mechanical clamps, which may be shown in photos and videos, are not part of the scope of delivery.
https://www.hoechsmann.com/14025
2025-11-20 10:00:04
- Germany
- Second hand
