Year of manufacture 2011
Sanding width 1.350 mm
Workpiece thickness min 4 mm
Passage height max 200 mm
Protection against workpiece over-thickness
Workpiece length min 365 mm
Sanding aggregates total 3
Sanding rollers 3
Walzenhärte min 65 Shore
Hardness grade of roller in ° shore 85 Shore
Sanding pads total 1
Segmental pressure pad electronic
DMC Segmental pressure pad EPICS
Segment width 30 mm
Jump-in control electropneumatically
Jump-in control
Cleaning brush Yes
Constant passline height
Sensing of workpiece thickness mechanical
Main motor power 18,5 kW
Sanding belt length 2.620 mm
Belt speed max 33,5 m/s
Feed min 4,5 m/min
Feedrate max 18 m/min
Continuously variable feed
Blow-off device Sanding belt, Workpieces
Rotating nozzles
Configuration of aggregates r-r-p-u
Side of belt change Left
Control DMC HYDRA V-PAD
Declaration of CE-conformity
Conformity marking CE mark
Weight 3.600 kg
Space requirement Length 3,05 m
Space requirement Width 2,1 m
Space requirement Height 2,5 m
https://www.hoechsmann.com/56434
2025-10-06 17:45:58
- Germany
- Second hand
