Year of manufacture 2011
Sanding width 1.350 mm
Workpiece thickness min 4 mm
Passage height max 200 mm
Protection against workpiece over-thickness
Sanding aggregates total 3
Sanding rollers 3
Hardness grade of roller in ° shore 85 Shore
Combination unit 1
Sanding pads total 1
Cleaning brush Yes
Constant passline height
Sensing of workpiece thickness mechanical
Main motor power 18,5 kW
Sanding belt length 2.620 mm
Feed min 4,5 m/min
Feedrate max 18 m/min
Continuously variable feed
Blow-off device Sanding belt, Workpieces
Rotating nozzles
Configuration of aggregates r-r-c-u
Side of belt change Left
Control DMC HYDRA V-PAD
Conformity marking CE mark
Weight 3.700 kg
Space requirement Width 2,1 m
Space requirement Height 2,5 m
